Which WRCCA rules does this guide cover?
This guide uses the 2026–2027 WRCCA Official Rules, dated January 1, 2026, checked on October 27, 2026. The class definitions are in sections 2.2–2.6. It is an independent reading aid, not an official rulebook or approval of a particular build. Confirm the version and local amendments used by your event.
Start with the class, then choose the chassis. The five families covered here are Super, Pro, Mini, Sportsman and Performance Scale. A small truck is not automatically Mini-legal, and a scale-looking crawler is not automatically legal for Performance Scale.
WRCCA classes at a glance
| Class | Wheelbase | Wheels and tires | Defining build check |
|---|---|---|---|
| Super (§2.2) | 16–18 inches | Minimum 3.2-inch wheel bead surface | Unrestricted steering; body or bodiless chassis |
| Pro (§2.3) | Maximum 12.5 inches | Maximum 2.55-inch wheel exterior; 6-inch tire OD | Two-wheel steering; body or bodiless chassis |
| Mini (§2.4) | Maximum 9 inches | Maximum 2.2-inch wheel exterior; 4.95-inch tire OD | Front steering; one chassis-mounted motor, one ESC, one servo |
| Sportsman (§2.5) | Maximum 12.5 inches | Maximum 2.55-inch wheel exterior; 6-inch tire OD | Bodied only; one chassis-mounted motor, one ESC, one servo |
| Performance Scale (§2.6) | Check body/chassis geometry requirements | Maximum 2.55-inch wheel exterior; 4.8-inch tire OD and 2.16-inch tire width | Scale body requirements; shaft drive, one motor, front steering |
Wheel exterior is not bead diameter. Where the rules specify an exterior limit, include the beadlock ring with the tire mounted. A “1.9” or “2.2” product name alone does not answer that measurement. Tire OD means outside diameter; use the class's specified measurement method.
The general wheelbase check uses axle-nut centers and the maximum reached through suspension travel, on both sides of the ready-to-run rig. A setup that meets a limit only while sitting at rest can still fail inspection.
Super vs Pro: choose the architecture before buying
Super's larger wheelbase envelope changes the scale of the entire build. Pro's shorter envelope still allows a purpose-built competition layout. In either case, start by checking chassis, axle and drivetrain compatibility together; a chassis listing is not a complete running vehicle.
Research Super-class catalog parts or the 2.2 Mod / Pro-oriented catalog. For axle-specific research, the Berg and Bully 2 pages keep parts tied to their platform. A part appearing in a class collection is a research starting point, not a claim that the finished truck passes WRCCA tech.
WRCCA Mini rules: the checks that shape a build
Mini has a 9-inch (228.6mm) maximum wheelbase and a 4.95-inch (125.73mm) maximum tire outside diameter. It permits a body or a bodiless chassis, but constrains the drivetrain and controls: one chassis-mounted motor drives both axles, with one ESC, one steering servo and two used radio channels for steering and throttle. Dig and other driver-controlled devices are not allowed. Each axle needs at least three suspension links; check §2.4 for the full construction requirements.
For a Mini project based on UTB18 components, start with the Capra UTB18 platform catalog and compare the chassis maker's required links, transmission and mounts. The 1.9 Mini catalog collection uses a familiar catalog label; it does not replace the current rulebook's wheel-exterior measurement.
How is Sportsman different from Mini and Pro?
Sportsman uses the larger 12.5-inch envelope and is bodied only: a bodiless Pro-style chassis does not satisfy that requirement. Like Mini, its controls and drivetrain are restricted to one ESC, one chassis-mounted motor, one servo and two used radio channels. The practical shopping question is therefore not just “will this chassis fit?” but “can this complete body, drivetrain and control layout meet my class?”
Use the 2.2S / Shafty catalog to research that layout, then verify the body and all class-defining dimensions against §2.5.
Performance Scale: check the body before the parts basket
Performance Scale adds body and chassis requirements that do not reduce to a generic wheelbase number. Among the checks in §2.6 are a body at least 3 inches longer than the wheelbase, a cabin at least 5 inches wide and 4.25 inches tall, and front lower links at least 90mm eye-to-eye. Tire size and construction also matter: the class does not permit cut-and-shut resizing or pin tires.
Lay out the intended body, axle centers, links and bumper before ordering a chassis. Confirm the full grille, body-piece, bumper, battery and electronics rules in the source. Read the general crawler-class guide if a seller mixes scale-class labels; WRCCA Performance Scale is not automatically equivalent to a club's Class 1, 2 or 3.
The Performance Scale catalog collection can help identify candidate parts. Its broad fitment tags do not certify a complete competition build.
Turn a rule limit into a useful parts shortlist
- Confirm an event and class. Ask which rules edition and amendments it uses before choosing a class-defining chassis or body.
- Write down the interfaces. Record axle family, transmission, link mounts, shaft connections, wheel mounting and electronics space. Shop by those details as well as the class name.
- Check dimensions as a system. A tire, wheel and hub combination can alter clearance and width; a link or shock change can alter the maximum wheelbase through travel.
- Compare the exact product's offers. Open its catalog page for available merchants, price and stock information, then verify fitment with the seller. Keep installation hardware and required companion parts on the same list.
For a first build, adjustable geometry and readily available replacement parts can be more useful than chasing the lightest component. Keep a setup sheet so a change that helps one obstacle can be checked against the rest of the course.
Common WRCCA class questions
Which rulebook should I use for WRCCA rules in 2026?
The source linked above is titled 2026–2027 and dated January 1, 2026. Use it alongside the document and amendments named by your event organizer, rather than an undated setup post.
Does “Mini” mean any small-scale crawler can enter?
No. Size is only one check. The drivetrain, controls, steering, suspension and body or bodiless-chassis requirements also apply. Inspect a proposed donor vehicle against the full Mini section before buying conversion parts.
Can a Pro chassis also run Sportsman?
Do not assume so. Sportsman requires a body and a restricted drivetrain/control layout. Whether parts can be reused depends on the finished configuration, not the chassis's marketing name.
Which class is best for a beginner?
Start with a class that has local drivers willing to help and events you can attend. Watch a course, ask about parts support and inspect a few complete rigs before choosing your build. A well-supported local class gives you a practical way to test and improve.
Before event day: a short tech checklist
- Confirm the active rules edition, amendments and inspection procedure.
- Measure wheelbase through suspension travel, with the rig ready to run.
- Check wheel exterior or bead-surface dimensions as specified for the class, plus tire dimensions and construction.
- Check body or bodiless dimensions, steering, drivetrain, used radio channels and allowed devices.
- Inspect fasteners, shaft engagement, wiring and clearance after the last setup change.
- Read the event's scoring and repair procedures before the driver meeting.
A test fit or a catalog compatibility label cannot replace inspection of the complete rig. Bring any uncertain dimension or unusual configuration to the organizer before registration.
